900*130mm PVC PU PVK PE Conveyor Belt Air Cooled Joint Hot Press Splicing Machine

1.0 piece
MOQ
900*130mm PVC PU PVK PE Conveyor Belt Air Cooled Joint Hot Press Splicing Machine
Χαρακτηριστικά Εκθεσιακός χώρος Περιγραφή προϊόντων Ζητήστε ένα απόσπασμα
Χαρακτηριστικά
Προδιαγραφές
Warranty: 1 Year
Type: Other
Applicable Industries: Manufacturing Plant, Machinery Repair Shops
Showroom Location: None
Video outgoing-inspection: Provided
Machinery Test Report: Provided
Marketing Type: Hot Product 2020
Warranty of core components: 1 Year
Core Components: PLC, Motor, Gear
Condition: New
Application: Textiles
Packaging Type: Belt
Packaging Material: Plastic
Automatic Grade: AUtomatic
Driven Type: Power
Voltage: 220/380/415V, 3 phase, 220/380/415V,3AC
Power: 4.5KW, 4.5KW
Weight: 65 KG
Dimension(L*W*H): 1105*250*225mm
Key Selling Points: PLC automatic working
Model: UQ-A900
Effective joint size: 900*130mm
After-sales Service Provided: Video technical support
Πιστοποίηση: CE, ISO
Βασικές πληροφορίες
Πιστοποίηση: CE, ISO
Model Number: UQ-A900
Πληρωμής & Αποστολής Όροι
Packaging Details: Standard export carton package
Supply Ability: 100 Piece/Pieces per Month
Περιγραφή προϊόντων

                                                                               Company Introduction



Unique Machinery (Shanghai) Co,.Ltd, founded in 2015, is a new and passionate company.We specialize in providing different type machines for pvc & tpu conveyor belts--ply separator, v-finger punching machine,belts
cutting machine,hot press joint machine,hole punching machine HF cleat & side wall welding machine,etc.
Thanks to hard working of "Unique people". we have opened market in Asia, Europe, S. Africa and provided machine and service to conveyor belts customers in those countries. Look forward to the future, Unique people would keep the concept of " Quality is first , customer is supreme ", & provide best quality goods and service to conveyor belts customers all over the world. Welcome new and old customers to contact us for new cooperation.

Products Description
900mm air cooled hot press for PVC/PU Conveyor Belts Joint


Air cooled all-in-one designed splicer is the new generation of splice equipment for belt

joint splicing both on site and in the workshop.Unique air cool splicing press is less weight,

less set-up time, and very short splicing time.

Standrad joint size

300*130mm,600*130mm,900*130mm,1200*130mm, 1500*130mm,1800*130mm,

2100*130mm,etc.

Machine features

01. Integrated type cooling system, no need cooling water.

02. Easy to move in luggage box. suitable for belts joint at site.

03. Fast welding and cooling: whole working process within 7-15mins.

04. One-piece equipment, no external component. Easy to installation and operation.

Technical Datas

Model  UQ-A900
Power 4.5KW
Voltage 220V/380V/415V, 1 or 3 PH, 50/60HZ
Effective joint size 900*130mm(36''*5.1'')
Net weight 65KG
Machine size L1105*W250*H225mm



I.Cleats & Side wall Welding Machine



Unique high frequency welding machine is special for pvc/tpu cleat, side wall welding.

I. Mahcine configurations:

uElectronic tubes:TOSHIBA  uSpark protection plate:NL5557 uPower relay: OMRON uTime relay: OMRONuA.C contactor: Mitsubishi  uAir switch: MitsubishiuAir cylinder: Airtac  uPress-button:  Taiwan AP   uCounter:  Taiwan ANLY   u0il-water separator solenoid valves: AirTAC uHigh frequency power output shielding: whole machine protection

II. Technical datas:

Model

UQ-12000T

HF output

12KW

Power input

18KVA

Voltage

380V,3 A.C.

Frequency value

27.12MHZ

Rectifier

Silicon diode

Power Type

Pneumatic

Upper plate size

400*650

Bottom plate size

800*800

Upper plate Max.rise

170mm

Machine size

1200*860*2000mm

II.Air Cooled Hot Press




   Unique air cooled press machine

Air cooled all-in-one designed splicer is the new generation of splice equipment for belt

joint splicing both on site and in the workshop.Unique air cool splicing press is less weight,

less set-up time, and very short splicing time.

Standrad joint size:

300*130mm,600*130mm,900*130mm,1200*130mm, 1500*130mm,1800*130mm,2100*130mm,etc.





III.High Precise Ply Separator


Unique New belt ply Separators (splitting machines)

It is used for belts splitting, suit various belt thicknesses and easy operation, 130mm deepth separation

Unique new belt sply separator advantages

1.  With scale, high precision separation, high effiency Layered thickness accuracy.
2.  Scale to adujust the split deepth. Max. 130mm.
3.  Hard alloy steel knife,more durable and sharper.
4.  With cover &  pedal switch,, work more safe and easy operation.
5.No belt thicknesses limited. Belts can be divided into two layers, three layers, or four layers, etc.

Specification & Main Components

Controller:Positive/Inversion control box
Switch: Foot pedal start / stop
Voltage: Standard 380V 3 phase ,or customerized
Power: <180W
Splitting thickness:0.8-15mm, PU, PVC, Rubber belt etc. Conveyor belts


IV. Semi-Auto V-finger Punching Machine


 Pneumatic type V finger punching machine

This type finger puncher is semi-automatic and pneumatic.Suitable for prepping finger and finger-over-finger splices for PVC,PU and polyurethane belts;Standard type: 1600mm, also can make smaller 1000mm and wider 2000mm, Punching teeth size: 20*50, 10*80. 20*80mm,etc.





V. Conveyor Belts Cutting Machine


UQ conveyor belts cutting machine Max. cutting width 4500mm.Max. cutting

thickness can reach 20mm. It is suitable for pvc/tpu/rubber belts cutting and slitting.

Machine Features:

High-precision conveyor belts vertical slitting

cutting error: +-0.05mm suitable for high quality workshop conveyor belts slitting.

Round or streight cutting knife design can meet different customer requirement.

Cutting width, machine voltage, can be custom made.

 Cutting Machine + Automatic Unwinder And Rewinder Parts


Cutting machine + Roll Belts Holder



PVC/PU/RUBBER Conveyor Belts Hole Punching Machine

Unique automatic holes punching machine can work on very solid and hard PVC/PU/Rubber belts. Hole punching tools diameter range from 2mm to 10mm.Machine setting(hole distance and number) isprogrammable. PLC touch screen control whole working process. Effective roller width: 500,1000,1500, 2000mm or customized

Maximum length of belt: unlimited; Minimum length of belt: 500mm; Maximum perimeter of belt:unlimited;

Minimum perimeter of belt: 600mm; High pression : +- 0.05mm
